Features
- 48 Port 2.5G Switch, 48×2.5g Ethernet port
- 4x10G SFP+ports
- 2x 40G ports
- Support three-layer
- Support IPV6
- Support 6kV lightning protection
- 72Mb cache
- 4x silent fan
- Usage scenarios: high-speed enterprises, internet cafes, esports hotels
Specification
| Model | LL-L3MES-SW-2.5G48-40G |
| Port | 48 x 100/1000/2500M Ethernet Port 4 x SFP+ Port 2xQSFP+ 40Gbps 1x Management Port 1 x Console Port |
| Switching Capacity | 1.28Tbps |
| Packet forwarding rate | 952.32Mpps |
| Appearance size | 1U19 inches |
| Input power supply | AC: 110-240V/50-60Hz |
| L3 Software Features | ERPS/ECMP/MLAG/IGMP Snooping/SNMP/DHCP Server/DoS/ACL control/LACP/MAC address/QoS/Link Aggregation/Spanning Tree And More. |
| size | 442*290*44mm |
| Working environment | Working temperature: -5~50 ℃ Storage temperature: -20~70 ℃ Working humidity: 10%~90%, non condensing Storage humidity: 5%~90%, no condensation |
Alisa Watts –
This switch is extremely good value for all the features and functionality! It’s almost identical to Cisco IOS/Nexus at the CLI and has a decent Web UI that allows you to configure the most common settings. To configure the switch over the serial console, set your terminal emulation to 115200-8N1 using the credentials admin/admin.
Thanks to the seller for a great product!
